Remote Control Orange Peel Grab is mainly used for loading block cargo with single hook crane, such as stone, pig iron,woodchips. The opening speed of the grab can be varied automatically to adapt to block cargo with different levels.
Remote Control Orange Peel Grab
Remote Control Orange Peel Grab is mainly used for loading block cargo with single hook crane, such as stone, pig iron,woodchips. The opening speed of the grab can be varied automatically to adapt to block cargo with different levels.
| Type | Volume(m3) | Crane Capacity
(t) |
Dead Weight
(t) |
Dimensions (mm) | Sheave Dia. (mm) | Steel Rope Dia. (mm) | |||
| A | B | C | D | ||||||
| YKD7[1]4 | 1 | 7 | 4 | 2310 | 3078 | 2700 | 3202 | Æ400 | Æ20 |
| YKD16[10]7 | 10 | 16 | 8 | 3640 | 5816 | 5259 | 5533 | Æ520 | Æ28 |
| YKD25[6]11 | 6 | 25 | 11 | 3600 | 4354 | 4798 | 5506 | Æ650 | Æ36 |
| YKD25[22]13.5 | 22 | 25 | 13.5 | 4540 | 6350 | 5970 | 6337 | Æ650 | Æ36 |
| YKD28[13]12 | 13 | 28 | 12 | 4300 | 5511 | 5626 | 6720 | Æ650 | Æ36 |
Note:1.As the products have been improved, we will not advice another.
2.We can design and produce the grab according to user’s demand.
